OETIKER CV Boot 304 SS Adjustable Ear Clamp - Small 25 - 50mm

Oetiker©159 Series Adjustable Ear Clamps are manufactured in 304 SS and its choice of engagement positions enable the Oetiker clamp to be adjusted to several nominal diameters. The Multi-position interlock consists of one or two load retaining hooks that enable the ear clamp to withstand tensile loading during closure and a lock tab designed to hold the hooks in their windows prior to closure. Often used for CV Boot Joints

Applications

Agriculture, Mining, Construction, Military, Aircraft, Ship Building, HVAC, Chemical Industry, Medical equipment, Vending Machines, spray equipment, Caravan Manufacturers, Compressed Air Systems, Commercial Vehicles, Welding Equipment

Product Specifications

Min Diameter - A 100.00mm - 3.937"

Max Diameter - A 108.0mm - 4.252"

Band Width - B 9.0mm - 0.354"

Band Thickness - C 0.6mm - 0.024"

Material W4 Stainless Steel AISI 304

Corrosion Resistance - DIN EN ISO 922 >1000 h

Weight 0.017kg/0.037lbs

Also known as O Clip, Pinch on Clamp, Step less ear Clamp

Manufactured By Oetiker

Oetiker Part Number 16300022

Hazardous Goods No

RoHS Compliant Yes
